Hipot testers/Electrical Safety Analysers

  1. Hipot is an abbreviationhigh potential. Traditionally, hipot is a term given to a class of electrical safety testing instruments used to verify electrical insulation in finished appliances, cables or other wired assemblies, printed circuit boardselectric motors, and transformers.

Under normal conditions, any electrical device will produce a minimal amount of leakage current due to the voltages and internal capacitance present within the product. Yet due to design flaws or other factors, the insulation in a product can break down, resulting in excessive leakage current flow. This failure condition can cause shock or death to anyone that comes into contact with the faulty product.

A hipot test (also called Dielectric Withstanding Voltage (DWV) test) verifies that the insulation of a product or component is sufficient to protect the operator from electrical shock. In a typical hipot test, high voltage is applied between a product's current-carrying conductors and its metallic shielding. The resulting current that flows through the insulation, known as leakage current, is monitored by the hipot tester. The theory behind the test is that if a deliberate over-application of test voltage does not cause the insulation to break down, the product will be safe to use under normal operating conditions—hence the name, Dielectric Withstanding Voltage test.

  • Filter

*0.1 to 5 kV AC Hipot/AR IR (all models) *Insulation Resistance True RMS Current Readback *Test Time 1 to 180 Sec or Continuous *Arc Detection *3 Ranges of Adjustable Out Off Current *Simultaneous Digital Display for Voltage, Current and Timer *Zero Turn-On Operating Switch Automatic FAIL Indicator with Alarm Lamp and Buzzer *9-Pin Remote Control for START, RESET *Voltage Output Adjustable During Test Period 1-Year Warranty

*5000V AC, 5000V DC *True RMS Current read-back *Arc Detection *Zero Crossing Turn-On *3 ranges of adjustable cut-off current *Digital display for voltage, current and timer at same time *Automatic FAIL indicator of alarm lamp and buzzer *Remote control for START, RESET, and Pass/Fail *Voltage output adjustable during test period 1-Year Warranty

FEATURES ● This a simplified Version of an appliance tester which use    low voltage and low current to perform it's checks.● Application Example   The appliance is plugged into the mini appliance checker, then the   probe make contact with the protective conductor.● Other appliance checking   Washing Machine Toaster Iron Dish Washer   Stove     SPECIFICATIONS     ELECTRICAL Resistance Ranges    The L-E led will lit when the resistance between Line    to Earth is lower than 1MΩ ±5% .    The N-E led will lit when the resistance between Neutral to Earth is lower    than 1MΩ±5%  The EARTH BOND led will lit when the resistance between the EARTH to the Probe is higher than 10Ω±5% . Test Current    Line to Earth test current is 9uA maximum.    Neutral to Earth test current is 9uA maximum.    Earth to Probe test current is 2.3mA maximum. Maximum Output     Voltage    9V...
